Emergency Driver 3-9W/ 10-20W
10.0 USD
Min. Order:
100 Piece/Pieces
Trade Term:
FOB,EXW
Payment Terms:
T/T, WU
Place of Origin:
Guangdong, China (Mainland)
Means of Transport:
Ocean, UPS, dhl, Air
Production Capacity:
50,00pcs a week
Packing:
netual packing
Delivery Date:
7-12days
Input:
110-270V,50~60Hz
Custom:
Acceptable
Certificate:
CE, RoHS
Warranty:
3 years
- Product Description
- Related Products
- Related Links
-
LED Emergency Driver 3-9W
An emergency backup driver supplies regulated backup power to LED light fixtures during a power outage. Backup drivers continuously monitor the power line for disruptions so that in the event of a power failure, they can automatically switch power from the main supply to the battery.
The Self‑Test Emergency driver is Suitable for 12‑48VAC low‑voltage LED luminaires and circuits.
Its built‑in microprocessor self‑test circuit complies with BS5266, performing automatic commissioning, monthly functional tests and annual 3‑hour full‑duration tests.
It detects lamp‑chip series configuration and adjusts output voltage for optimum‑inverter‑load matching, enabling customised reduced‑illumination emergency mode.
Specification
Support LED Power Range
Max.18W
Emergency Output Power
3W-9W(7.4V)/10W-20W(11.1V)
Input Voltage
AC/DC 12V-48V
Output Voltage
DC 12V-48V
Battery Voltage
7.4V/11.1V
Emergency Operation Duration
>90Minutes or bespoken
Working Environment
0-50℃,65+20%RH
Power Factor
>0.9
Charge Time
≥24hours
Inverter Size
Metal:137*34*26mm/PC:150*36*30mm
Warranty
Three Years
