18W 300*300mm LED panel lights

Place of Origin: Guangdong,China (Mainland)
Brand Name: Prime
Input: 110-270V,50~60Hz
Color: White/warm white
CCT: 3000/4000/6000K
CRI: Ra80
Angle: 120deg.
Certificates: CE, RoHS UL
Warranty: two years

inquiry

skype basketAdd to Basket  Edit

Share |

Product Description

Payment & Shipping Terms Supply Capacity
Unit Price:20.0~50.0 USDProduction Capacity:3000pcs a week
Trade Term:FOBPacking:netual
Payment Terms:T/TDelivery Date:10-15days
Min. Order:2 Piece/Pieces
Means of Transport:UPS DHL, Ocean, Air

18W 300*300mm LED panel lights home led lighting supplier ltd


18W 300*300mm LED panel lights

18W 300*300mm LED panel lights home led lighting supplier ltd
with 6063 aluminum frame as heat sinking parts as well as 4mm thick lighting guide panel, (3mm thick lighting guide panel is avaiable as well, at lower costs), are pretty nice as replacement of CFL receesed downlight, with honglitronic 2835 SMD, with output of 1100-1300Lm, white and warm white  optional,


Features:

1. Save 60-70% on the electricity bill and maintenance cost;

2. Long life to 40,000hours;

3. No delay to light on;

4. No UV or IR radiation, NO mercury;

5. Aluminum alloy housing and Optical PMMA cover;

6. Two years Guaranteed

Specification

> Power consumption: 18W

> Color: 5500K (White)
> Output: 1100-1300LM
> Dimension: 300*300x12mm

> Beam angle :> 120degree

> CRI: >75, 80(samsung)

The Curves indicate the illuminated area and the average illumination when the luminaire is at different distance.


18W 300*300mm LED panel lights

Item18W 300*300mm LED panel lights home led lighting supplier ltd

PartNo.

PPL-0303-18W/PPL-0303-18W

Size

300*300*12mm

Power

18W

Lumens Output

1100-1300LM

Color

White / Warmwhite

LED Type

3014 SMD or 5630 SMD

LED Qty

176pcs 3014 smd or 48pcs 5630 smd

Input Voltage

110-270V AC,50~60Hz

CRI

75 or 80

Beam Angle

120

Lifespan

50,000hours

OperatingTemperature

-20~65 degreesCelsius


Indoor Use,IP42

There are three colour/Kelvin options, for 18W 300*300mm LED panel lights home led lighting supplier ltd:

6000-6500K– Ideal for kitchens, workshops, medical areas where a higher intensity, cleaner light is required.

4000-4500K– Ideal for offices, corridors, kitchens.Most popular kelvin as closest to fluorescent.

2700-3200K– Idea for Areas where reduced intensity lighting is needed. Looks good in all of the above and gives a warmer glow with the same level of light.

18W 300*300mm LED panel lights


How A Prime LED Panel light comes out?

As we source LEDs for the panel lights originally from Samsung, LumenMax and HONGLI, so NO packaging and sorting jobs in Prime LED's.

36/42/48/54W 600*600mm LED Panel Light
36/42/48/54W 600*600mm LED Panel Light


How to order samples?

1, Samples are available at your costs;

2, You tell us which items, color and quantity you want, 5pcs as MOQ;

3, I will issue a Performa invoice for the samples order;

4, Production will go, if we do not have the stocks, after your payment by TT / Western Union;

5, Samples will be sent out by DHL or UPS, as you like.

Warranty Terms:

1. Prime LED offers a warranty period of TWO years since the date cargos was shipped out;

2. Prime LED will send free replacements or parts, after our confirmation of the evidence we request, if failure occurs under normal and right application within the period;

3. Prime LED will offer you charged replacements or parts, if failure or damage due to incorrect operation or application.
